WHY ECO STAR SERIES
This range of glass combine the properties of Tranquility and Eco plus to give you the perfect glass for your window application. Eco Star gives you unmatched safety with superior acoustic control and security while giving you major energy saving. No need for grills to spoil the view. Eco Star is also a security glass and will not all on intrusion.
Features
Energy Reduction
Reduce the direct heat coming to the building & also reduce air conditioning costs.
UV CONTROL
Screens out 99% of the sun’s damaging rays, protecting interior furnishing, displays or merchandise from fading effects of UV radiation.
SECURITY & SAFETY
Resists intrusion because the inter layer continues to safeguard the building even after the glass itself is broken. doesn’t shatter like ordinary glass.
Sound Reduction
It is an excellent barrier to noise. The sheer damping performance of the plastic inter layer make the glass an effective sound control product.
THERMAL INSULATION
Saves on heating and cooling by reducing air to air heat transfer.
CLEAR VIEW
Gives clear view without obstruction. Grills are not required in Eco Star Series
Eco Star
Eco Star is recommend for shaded are a with security risk and noise.
Eco Star SC (Solar Control)
Eco Star SC to be used in area with direct sunlight for better energy reduction. It controls the solar factor and ultimately reduces the air conditioning cost.
Eco Star TC (Thermal Control)
Eco Star TC to be used in area with no direct sunlight(shaded). It is best suited for thermal insulation
Eco Star Plus (Solar + Thermal Control)
To be used for area with direct sunlight for solar as well as thermal insulation for resulting in excellence energy reduction
eco star range
Eco Star
Laminated Insulated glass made up of 13.52 Security Glass as interior glass and 6 mm clear toughened glass as exterior glass with 12 mm air gap
Eco Star SC (Solar Control)
Laminated Insulated glass made up of 13.52 Security Glass as interior glass and 6 mm clear solar control toughened glass as exterior glass with 12 mm air gap
Eco Star TC (Thermal Control)
Laminated Insulated glass made up of 13.52 Security Glass as interior glass and 6 mm clear low-e toughened glass as exterior glass with 12 mm air gap
Eco Star Plus
Laminated Insulated glass made up of 13.52 Security Glass with solar control glass as interior glass and 6 mm clear low-e toughened glass as exterior glass with 12 mm air gap
product comparison
Energy Reduction
Thermal Insulation
Safety & Security
Light Transmission
| Product | Thickness(MM) | Strength | Safety | Security | Sound | Solar Factor | U-Value | RHG (Watts/Sq.M) | Visible Light Transmission | Sunlight (Reduction) | Shaded (Reduction) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 6MM Clear Glass | 6 | 7 | 7 | 1 | STC26 | 0.82 | 5.7 | 603 | 89% | 5% | 14% |
| Eco Star | 31.52 | 9 | 10 | 7 | STC41 | 0.62 | 2.7 | 431 | 77% | 28% | 53% |
| Eco Star SC | 31.52 | 9 | 10 | 7 | STC41 | 0.55 | 2.7 | 387 | 58% | 36% | 53% |
| Eco Star TC | 31.52 | 9 | 10 | 7 | STC41 | 0.66 | 1.8 | 443 | 67% | 27% | 68% |
| Eco Star Plus | 31.52 | 9 | 10 | 7 | STC41 | 0.49 | 1.8 | 336 | 51% | 44% | 68% |
Faq
What is solar control glass ?
A solar control glass is a glass with a special coating designed to reduce the amount of heat entering a building. It reflects and absorbs heat as well as filters light from windows and doors for reduced glare. Using a solar control glass reduces the need for air-conditioning and blinds.
What is low-e glass ?
Low-e coatings have been developed to minimize the amount of ultraviolet and infrared light that can pass through glass without compromising the amount of visible light that is transmitted.
what is solar energy spectrum or energy from the sun ?
Ultraviolet (UV) light, visible light and infrared (IR) light all occupy different parts of the solar spectrum – the differences between the three are determined by their wavelengths.
- Ultraviolet light, which is what causes interior materials such as fabrics and wall coverings to fade, has wavelengths of 310-380 nanometers when reporting glass performance.
- Visible light occupies the part of the spectrum between wavelengths from about 380-780 nanometers.
- Infrared light or heat energy, is transmitted as heat into a building, and begins at wavelengths of 780 nanometers. Solar infrared is commonly referred to as short-wave infrared energy, while heat radiating off of warm objects has higher wavelengths than the sun and referred to as long-wave infrared.
